Custom Stainless Steel Cable Marker Plates - Expertly Crafted At Our Factory

Stainless Steel Cable Marker Plate

● Use manual marking machine or laser marking machine to engrave information on it; ● Fixed with self-locking cable tie; ● Made from SS201, 304, 316 stainless steel, superior corrosion resistance.

Type	Specification (W×L)mm	Thickness	Package M/bag	Weight
ID4000	9.50×89.0	0.40mm	100	0.2
ID4020	19.0×89.0	0.40mm	100	0.4
ID6000	9.50×89.0	0.40mm	100	0.2
ID6020	19.0×89.0	0.40mm	100	0.4
ID8000	20.0×70.0	0.25mm	100	0.2
ID8020	25.0×25.0	0.80mm	100	0.4

Stainless steel cable ties are very suitable for use in high temperature areas because they can withstand higher temperatures than ordinary cable ties. Due to their cold resistance, they also have a higher breaking strain, which means that they will not deteriorate in harsh environments. But they also have disadvantages. You cannot use uncoated stainless steel cable ties in situations where they will come into contact with galvanized metal because they will react. To avoid this, you can use a third material as a barrier or use coated stainless steel cable ties. The width of uncoated stainless steel cable tie is 4.6mm and 7.9mm, and the length is: 150mm, 200mm, 300mm, 360mm, 520mm. Stainless steel cable ties are very suitable for industrial enterprises and mechanical garages. 1. Selection method of stainless steel cable tie 1. First of all, you must confirm the working condition of your binding object, whether it is a corrosive environment or an ordinary natural environment, and choose the right material. 2. Confirm the requirements of the object you are binding, whether it requires very tightness, or just ordinary tightening, whether it is hard, hard, hard or soft, and determine different styles of ties, such as rolled stainless steel ties, bags Plastic stainless steel cable tie, format stainless steel cable tie, bead type, coating and so on. How to use stainless steel cable ties 1. Place the stainless steel cable tie in the opening groove of the knife edge and the rotating shaft. 2. Move the gear handle back and forth to tighten the stainless steel belt. Editing analysis of mechanical principles 3. Push the handle forward, pull down the knife handle, cut off the packing belt, lock the buckle, and remove the tool.

Stainless Steel Cable Marker Plate
